Selling point
- We adopted variable type of heating roll.
- High-speed filling by shortened dropping distance.
- Beautiful sachet finishing off.
- We adopted shutter mechanism to prevent jamming of seal.
- You can use for mass production and also small-scaled, variety production.
Standard Specifications
Filling material
Powder or Granule
Pouch pattern
| 3-side seal |
|
Packaging capacity
20-200/min.
Filling volume
0.5-50cc * Weighing range of filling volume depends on the filling material and feeder.
Pitch variable range
2 wings 120-190mm
3 wings 80-130mm
4 wings 60-100mm
6 wings 40- 70mm
Width variable range
30-90mm
Film width
60-180mm
Film Diameter
φ400mm (Max.)
Power source
3-phase 200V Approx. 3kW in total
Air consumption
10L/min. (0.4-0.5MPa)
Machine Dimension
1,250mm (W) × 900mm (L) × 1,850mm (H)
Machine Weight
Approx. 400kg
Catalog Download
